Fanvil CP20 Technical Specifications
4K UHD Screen Sharing
- Resolution: Up to 4K/30fps with low latency
- Security: WPA3 data encryption
- Desktop sharing: Mirror and extended mode
Connectivity
- Wi-Fi: Wi-Fi 5/Wi-Fi 6
- Frequency band: 2.4GHz/5GHz
- Encryption protocol: WPA3-PSK
- Transmission Distance: up to 10 meters
- Frequency bands & max. transmitted power (EU):
- Wi-Fi 5GHz, Max 20dBm (Support for selecting corresponding 5G channels based on the country.)
Physical Specifications
- I/O Interface: Type C PD + DP ALT
- Operating Voltage: 5V
- Power consumption: 2.5W
- Buttons: Screen-Sharing/Volume up/Volume down/Freeze Screen
- LED indicator: 1 Red, 1 Green 个
- Freeze Screen Button
- Green light: Resume casting
- Red light: Pause casting
- Dimensions
- CP20 Screen-Sharing Pod: 189*40*18mm
- CP20 Screen-Sharing Pod USB cable length: 85mm
- Gift-box: 231*74.5*25.5mm
- Carton package: 602*432*260mm (112 PCS)
- Weight
- CP20 Screen-Sharing Pod: 62g
- Carton net weight: 14.79kg
- Carton gross weight: 16kg
- Temperature and humidity
- Working temperature: -10°C ~ +40°C
- Working humidity: 0% ~ 90%RH
Package Contents
- Screen-sharing Pod: CP20
- Quick Start Guide
Compatibility
- Mainstream UC/Video conferencing services
- Device: Compatible with Windows/Mac PCs, laptops, tablets and smartphones with full-featured USB-C
Compliance
