Fanvil GA100-32T FXO VoIP Gateway (GA100-32T)

The Fanvil GA100-32T is a high-capacity 32-port FXO VoIP gateway designed to convert analog telephone lines from operators and enterprise PBXs into SIP to connect to the softswitch system on the IP side. It delivers a powerful, stable, reliable, and cost-effective VoIP solution for IP call centres and multi-branch offices requiring large-scale analog line integration.

Supporting 32 concurrent calls across its 32 FXO ports, the GA100-32T provides seamless TDM-to-IP conversion with SIP/IMS protocols, VPN client functionality, and professional hardware-based echo cancellation. With 4 Gigabit Ethernet ports and strong compatibility with various softswitch platforms, it is built for high-demand enterprise deployments.

Fanvil GA100-32T Technical Specifications:

Generic

• 32 concurrent calls
• 32-channel (FXO) voice services
• TDM to IP call conversion
• SIP/IMS registration
• SIP agent
• NET settings
• Simultaneous registration of multiple servers (primary and backup)
• Centralised management
• Tone detector
• Number change
• Automated gateway configuration deployment
• ACL extension registration and web access support

Audio

• Narrowband codecs: G.711a/u, G.723, G.729A/B, iLBC, AMR
• DTMF: In-band, Out-of-Band (RFC2833 / SIP Info)
• Acoustic Echo Canceller (AEC)

FXO Features

• Caller detection
• Secondary dialling
• Polarity reversal detection
• Tone detection
• Outgoing call barring
• Incoming call blacklist
• FXO disconnection alarm

Network

• 10/100/1000 Mbps Ethernet
• IP mode: IPv4/IPv6
• IP configuration: Static IP / DHCP
• IP address and DNS domain name resolution
• VPN client support
• Firewall

Protocols

• TCP, UDP, HTTP/HTTPS, ARP/RARP, DNS, NTP, TFTP, TELNET, STUN, TR069, SRTP, TLS, SIP/IMS, SNMP

Deployment & Management

• Web management
• Supported languages: Chinese, English, Russian
• Firmware upgrades
• Web-based ping test / tracert test
• Administrator authentication
• System and service status monitoring
• Third-party centralised management support
• Automatic deployment
• Syslog (Error, Warning, Info, Debug)

Other Physical Features

• FXO ports: RJ11 ×32
• Ethernet ports: RJ45 ×4
• USB port: Mini USB ×1
• Lightning protection grade: Level 4
• Reset button: press and hold 8 seconds to restore factory settings
• Indicator lights: PWR, RUN, ALM, FXO
• Power consumption: <9W
• Working temperature: 0°C to 45°C
• Storage temperature: -20°C to 85°C
• Working humidity: 8% to 90%, no condensation
• Storage humidity: 8% to 90%, no condensation
• Product weight: 2.7 kg (3.3 kg with packaging)
• Dimensions (W x D x H): 44.0 x 20.2 x 4.4 cm

Package Contents

• 1 x Fanvil GA100-32T FXO VoIP Gateway
