Grandstream High-Performance Wi-Fi 6 Router (GWN7062M)

The GWN7062M is a dual-band AX3000 secure router delivering up to 3Gbps Wi-Fi speeds and supporting simultaneous connections for up to 256 wireless devices, allowing the GWN7062M to provide robust support for applications such as smart offices, home automation, smooth 4K ultra-high-definition streaming, network meetings, video conferences, and online gaming.

Grandstream GWN7062M Key Features

• Powered by Wi-Fi 6 (802.11ax) standard with up to 3Gbps wireless throughput
• Dual-band 2.4G 2×2:2 and 5G 3×3:2 MU-MIMO with technology
• Built-in VPN support allows easy access to corporate networks for remote employees
• Supports up to 256 concurrent Wi-Fi client devices
• Grandstream Home App, Grandstream’s mobile unified device management platform
• Powerful security features include guest network, network blacklist, Antihacking secure boot & critical data/control lockdown via digital signatures, and more
• Rich firewall features including Anti-DoS, traffic rules, NAT and ALG
• Supports Mesh networking with Grandstream routers to provide easy network expansion

Grandstream GWN7062M — High-Performance Wi-Fi 6 Router

Radio

Antenna

• 5 single-frequency antennas
• 2.4Ghz: gain5dBi
• 5Ghz: gain5dbi

MU-MIMO

• 2.4GHz: 2x2:2, MIMO
• 5GHz: 3x3:2, MIMO

Frequency Bands

• 2.4GHz radio: 2400 - 2483.5MHz.
• 5GHz radio: 5150 - 5895MHz

Channel Bandwidths

• HT20/40, VHT20/40/80, HE20/40/80/160

Wi-Fi Data Rates

• 5G:
  IEEE 802.11ax: 7.3 Mbps to 2402 Mbps
  IEEE 802.11ac: 6.5 Mbps to 1732 Mbps
  IEEE 802.11n: 6.5Mbps to 300Mbps
  IEEE 802.11a: 6, 9, 12, 18, 24, 36, 48, 54 Mbps
• 2.4G:
  IEEE 802.11ax: 7.3 Mbps to 573.5 Mbps
  IEEE 802.11n: 6.5Mbps to 300Mbps
  IEEE 802.11b: 1, 2, 5.5, 11 Mbps
  IEEE 802.11g: 6, 9, 12, 18, 24, 36, 48, 54 Mbps

Maximum TX Power

• 2.4G: 24 dBm
  5G: 26 dBm

Receiver Sensitivity

• 2.4G
  802.11b: -96dBm@1Mbps, -88dBm@11Mbps;
  802.11g: -93dBm@6Mbps, -75dBm@54Mbps;
  802.11n 20MHz: -73dBm@MCS7;
  802.11n 40MHz: -70dBm@MCS7;
  802.11ax 20MHz: -60dBm@MCS11;
  802.11ax 40MHz: -58dBm@MCS11;
• 5G
  802.11a: -92dBm@6Mbps, -74dBm@54Mbps;
  802.11n 20MHz: -73dBm@MCS7;
  802.11n 40MHz: -70dBm@MCS7;
  802.11ac 20MHz: -67dBm@MCS8;
  802.11ac 40MHz: -63dBm@MCS9;
  802.11ac 80MHz: -59dBm@MCS9;
  802.11ax 20MHz: -60dBm@MCS11;
  802.11ax 40MHz: -58dBm@MCS11;
  802.11ax 80MHz: -56dBm@MCS11;
  802.11ax 160MHz: -52dBm@MCS11;

Cover Range

• 150 square meter

Interfaces

Network Ports

• 1x 2.5G Combo SFP/RJ45 Ethernet WAN
  1x autosensing 10/100/1000Mbps Ethernet WAN/LAN, RJ-45
  1x 2.5G Ethernet LAN, RJ-45
  2x 1G Ethernet LAN, RJ-45

LEDs

• 1 tri-colour LED and 8x single-colour LEDs

Auxiliary Ports

• 1x Reset Pinhole, 1x SYNC, 1x POWER

Power

Maximum Power Consumption

• 18W

Physical

Dimension

• Unit: 205mm(L) x 130mm(W) x 35.5mm(H)
  Entire Package: 356mm(L) x 309.5mm(W) x 62mm(H)

Weight

• Unit: 400g
  Entire Package: 855g

Mounting

• Desktop or indoor wall mount

Package content

• GWN7062M router, Power Adapter, Ethernet Cable, Quick Installation Guide

Environmental

Temperature

• Operation: 0°C to 45°C

Humidity

• 10% to 90% Non-condensing

Compliance

• FCC, CE, RCM, IC

For the remaining technical specifications, please refer to the attached datasheet.
