Yealink MCore-OPS-G2T Modular Compute Module (Microsoft Teams)

The Yealink MCore-OPS-G2T is the Microsoft Teams-certified Gen 2 modular computing solution purpose-built for the Yealink MeetingBoard Series. Identical in hardware to the MCore-OPS-G2, the G2T adds the Microsoft Teams Rooms App and Yealink RoomConnect pre-installed, with Microsoft Teams certification out of the box. Powered by the Intel Core Ultra5 125H processor with built-in NPU (34 TOPS), 16GB DDR5 RAM, and a 256GB SSD, it delivers smooth performance for multiple simultaneous applications. It supports 4K content sharing via HDMI-IN and CEC-based automatic display wake. Enterprise-grade security includes TPM 2.0, UEFI Secure Boot, and Kernel DMA protection. Note: HDMI out is not available in Teams Rooms mode.

Yealink MCore-OPS-G2T Technical Specifications:

System Preload

• Windows 11 IoT Enterprise x64 operating system
• Windows 11 IoT Enterprise Licence
• Microsoft Teams Rooms App (supports Microsoft Teams meetings)
• Yealink RoomConnect

System

• CPU: Intel Core Ultra5 125H (built-in NPU 34 TOPS)
• Memory: 16GB (2×8GB) DDR5
• Storage: 256GB SSD

Interface

• 1× MTouch port (RJ-45)
• 1× LAN port (RJ-45)
• 1× HDMI out (not available in Teams Rooms mode)
• 1× HDMI in
• 2× USB 3.0 Type-A
• 1× USB 3.0 Type-C (without DP)
• Bluetooth 5.2 (AX201)
• WLAN: Wi-Fi 6 (IEEE 802.11a/b/g/n/ac/ax)

BIOS Features

• TPM 2.0
• UEFI Secure Boot
• Kernel DMA protection
• CEC support
• Custom boot logo

Other Physical Features

• Input: 12 – 19V, 4.7 – 7.5A
• Weight: 0.7 kg
• Operating Humidity: 10 – 90%
• Operating Temperature: -10 – 50°C
• Storage Temperature: -20 – 60°C
• Dimensions (W x D x H): 26.7 x 21.5 x 6.5 cm

Package Contents

• MCore-OPS-G2T
• 2× Antenna
• 2× Screw
• 1× Screwdriver
• 1× Quick Start Guide
