Fanvil X5U Enterprise IP Phone

The Fanvil X5U is an enterprise-level, two screen IP Phone. With all the necessary VoIP features and other extended features like an EHS headset and Wi-Fi dongle, the Fanvil X5U provides a high-quality and convenient user experience at an affordable price.

Fanvil X5U IP Phone Key Features

  • 16 SIP lines, 3-way conference, SIP hotspot
  • 1x3.5” main colour display, 1x2.4” side colour displays for DSS keys
  • 4 Line keys on the main display
  • HD audio on speakerphone and handset
  • Built-in Bluetooth for connecting Bluetooth headset
  • Supports Wi-Fi connectivity (Via Wi-Fi dongle)
  • Supports EHS wireless headset
  • Up to 30 DSS keys(6 two-coloured physical keys)
  • Dual Gigabit ports, integrated PoE
  • Stand with 2 adjustable angles of 45 and 50 degrees
  • 10/100/1000 Mbps Ethernet network
  • Compatible with major platforms such as: Asterisk, Broadsoft, 3CX, Metaswitch, Elastix, Avaya

Supports EHS Wireless Headsets
The Fanvil X5U supports EHS wireless headsets, for a professional VoIP phone experience

  Supports EHS Wireless Headsets

Fanvil X5U IP Phone - Technical Specifications

Generic

  • 16 SIP Lines
  • HD Voice
  • PoE enabled
  • 2 LCDs (Main + DSS)
  • Handset / Hands-free / Headst mode
  • Intelligent DSS Keys
  • Desktop stand/ Wall-mounted installation (needs additional wall handing parts)
  • Optional external power supply

Phone functions

  • Local Phonebook (2000 entries)
  • Remote Phonebook (XML/LDAP, 2000 entries)
  • Call logs (In/Out/Missed, 1000 entries)
  • Black/White List Call Filter
  • Screen saver
  • Voice Message Waiting Indication (VMWI)
  • Programmable DSS/Soft keys
  • Network Time Synchronisation
  • Built-in Bluetooth 2.1: Support Bluetooth headset
  • Supports Wi-Fi Dongle
  • Supports Plantronics wireless headset (Through Plantronics APD-80 EHS Cable)
  • Supports Jabra wireless headset (Through Fanvil EHS20 EHS Cable)
  • Supports Recording (Through Flash Drive or Server)
  • Action URL / Active URI
  • uaCSTA

Call functions

  • Call out / Answer / Reject
  • Mute / Unmute (Microphone)
  • Call Hold / Resume
  • Call Waiting
  • Intercom
  • Caller ID Display
  • Speed Dial
  • Anonymous Call (Hide Caller ID)
  • Call Forward (Always/Busy/No Answer)
  • Call Transfer (Attended/Unattended)
  • Parking/Pick-up (Depending on server)
  • Redial
  • Do-Not-Disturb
  • Auto-Answering
  • Voice Message (With server)
  • 3-way Conference
  • Hot Line
  • Hot desking

Audio

  • HD Voice Microphone/Speaker (Handset/Hands-free, 0 ~ 7KHz Frequency Response)
  • HAC handset
  • Wideband ADC/DAC 16KHz Sampling
  • Narrowband Codec: G.711a/u, G.723.1, G.726-32K, G.729AB, AMR, iLBC
  • Wideband Codec: G.722, AMR-WB, Opus
  • Full-duplex Acoustic Echo Canceller (AEC)
  • Voice Activity Detection (VAD) / Comfort Noise Generation (CNG)/ Background Noise Estimation (BNE) / Noise Reduction (NR)
  • Packet Loss Concealment (PLC)
  • Dynamic Adaptive Jitter Buffer
  • DTMF: In-band, Out-of-Band – DTMF-Relay (RFC2833) / SIP INFO

Networking

  • Physical: 10/100/1000 Mbps Ethernet, dual bridged port for PC bypass
  • IP Mode: IPv4/IPv6/IPv4&IPv6
  • IP Configuration: Static IP / DHCP / PPPoE
  • Network Access Control: 802.1x
  • VPN: L2TP / OpenVPN
  • VLAN
  • LLDP
  • QoS
  • RTCP-XR (RFC3611), VQ-RTCPXR (RFC6035)

Protocols

  • SIP2.0 over UDP/TCP/TLS
  • RTP/RTCP/SRTP
  • STUN
  • DHCP
  • IPv6
  • LLDP
  • PPPoE
  • 802.1x
  • L2TP
  • OpenVPN
  • SNTP
  • FTP/TFTP
  • HTTP/HTTPS
  • TR-069

Deployment & Management

  • Auto-Provisioning via FTP/TFTP/HTTP/HTTPS/DHCP/OPT66/SIP PNP/TR069
  • Web Management Portal
  • Web-based Packet Dump
  • Configuration Export / Import
  • Phonebook Import/Export
  • Firmware Upgrade
  • Syslog

Physical Specifications

  • Main LCD x1: 2.8-inch (320x240) Colour Screen
  • DSS Key-mapping LCD x1: 2.4-inch (240x320) Colour Screen
    Keypad: 42 keys, including
    - 4 Line keys (with LED indicator light)
    - 4 Soft-keys
    - 6 Function keys (Hold, Call forward, Conference, MWI, Headset, Redial))
    - 4 Navigation keys
    - 1 OK key
    - 12 Standard Phone Digits keys
    - 3 Volume Control keys (Up/Down/Mute (Microphone)
    - 6 DSS keys (With LED Indicator Light)
    - 1 Page-Switch (PS) key (With LED Indicator Light)
    - 1 Hands-free key (With LED Indicator Light)
  • HD Handset (RJ9) x1
  • Standard RJ9 Handset Wire x1
  • 1.5M CAT5 Ethernet Cable x1
  • Back Rack x1
  • Status Indicator Light x1 (Red)
  • RJ9 Port x2: Handset x1, Headset x1
  • RJ45 Port x2: Network x1, PC x1 (Bridged to Network)
  • USB2.0 Port x1: Standard A, Connect with Wi-Fi USB dongle or Flash Driver
  • Safety Keyhole x1
  • DC Power Input: 5V/2A
  • Power Consumption: (PoE): 1.7W~10.46W
  • Power Consumption: (Adapter): 1.38W~9.13W
  • Working Temperature: 0~45℃
  • Working Humidity: 10~95%
  • Installation:
    - Desktop Stand
    - Wall-mounted (need an additional wall hanging parts)
  • Color: Black
  • Device Dimensions:
    - Desktop Stand (Angles 1): 214x188.6x181.1 mm
    - Desktop Stand (Angles 2): 214x180.5x190.1 mm
    - Wall-mounted: 214x119.4x219.1 mm
  • Gift Box Dimensions: 315x228x84 mm
  • Outer CTN Dimensions: 476x440x335 mm (10 PCS)
