Fanvil X7A Android IP Video Phone

The Fanvil X7A is a high-end intelligent IP phone that combines sound, video and applications. Based on the Android 9.0 system, the interface is easy to use.

Fanvil X7A Key Features

  • 20 SIP lines, 3-way conference, hotspot
  • 7” capacity color touch-screen
  • HD voice: HD handset, HD speaker
  • Built-in Bluetooth 4.2 and 2.4G/5G Wi-Fi
  • Up to 112 DSS keys available at the display
  • Video Codec H.264 for receiving video calls
  • Dual Gigabit ports, integrated PoE
  • Stand with 2 adjustable angles of 40 and 50 degrees
  • Compatible with major platforms: Asterisk, Broadsoft, 3CX, Metaswitch, Elastix, Avaya etc.

It adopts a 7-inch color touch screen, built-in Bluetooth 4.2 module and 2.4G/5G Wi-Fi module, and integrates the USB 2.0 interface. X7A provides a rich and flexible desktop-class communication product solution for the communications and scalable value-added services of the enterprise-class user.
Fanvil X7A DSS Keys

Fanvil X7A Key Features Banner

Fanvil X7A- Technical Specifications

Generic

  • 20 SIP Lines
  • HD Voice
  • Support receiving Video call
  • PoE Enabled
  • 7-inch (1024x600) color touch screen
  • Handset / Hands-free / Headset mode
  • Intelligent DSS Keys(Virtual buttons)
  • Optional External Power SupplyDisplay

Phone Features

  • Android 9.0 OS
  • Local Phonebook (2000 entries)
  • Remote Phonebook (XML/LDAP, 2000 entries)
  • Call logs (In/out/missed, 1000 entries)
  • Black/White List Call Filter
  • Screen saver
  • Voice Message Waiting Indication (VMWI)
  • Programmable DSS/Soft keys
  • Network Time Synchronization
  • Built-in Bluetooth 4.2: Support Bluetooth headset
  • Built-in Wi-Fi 2.4GHz, 802.11 b/g/n
  • 5GHz, 802.11 a/n/ac
  • Support Recording
  • Action URL / Active URI
  • uaCSTA

Call Features

  • Call out / Answer / Reject
  • Mute / Unmute (Microphone)
  • Call Hold / Resume
  • Call Waiting
  • Intercom
  • Caller ID Display
  • Speed Dial
  • Anonymous Call (Hide Caller ID)
  • Call Forwarding (Always/Busy/No Answer)
  • Call Transfer (Attended/Unattended)
  • Call Parking/Pick-up (Depending on server)
  • Redial Do-Not-Disturb
  • Auto-Answering
  • Voice Message (On server)
  • 3-way Conference
  • Hot Line
  • Hot desking

Video

  • Wideband codec: G.722
  • Narrowband codec: G.711(A/μ), G.723.1,
  • G.729AB, iLBC, AMR
  • DTMF: In-band, Out-of-band(RFC 2833) and
  • SIP INFO
  • Full-duplex hands-free speaker phone with
  • AEC (Max filter length – 128ms)
  • Voice Activity Detection (VAD)
  • Comfort Noise Generation (CNG)
  • Adaptive jitter buffer
  • Packet loss concealment (PLC)
  • Audio format: WAV/MP3/OGG
  • Frame rate selection: 5~30fps
  • Video from remote site can be displayed in full screen

Deployment and Management

  • Auto-Provisioning via FTP/TFTP/HTTP/HTTPS/DHCP OPT66/SIP PNP/TR-069
  • Web Management Portal
  • Supports the third party communication APP
  • Supports Web, Telnet
  • Supports encrypted configuration files download with AES
  • Supports Web upgrade
  • Supports factory reset data

Audio

  • HD Voice Microphone/Speaker (Handset/Hands-free, 0 ~ 7KHz Frequency Response)
  • HAC handset
  • Wideband ADC/DAC 16KHz Sampling
  • Narrowband Codec: G.711a/u, G.729AB, iLBC
  • Wideband Codec: G.722, Opus
  • Full-duplex Acoustic Echo Canceller (AEC)
  • Noise Reduction (NR)
  • Packet Loss Concealment (PLC)
  • Dynamic Adaptive Jitter Buffer
  • DTMF: In-band, Out-of-Band – DTMF-Relay(RFC2833) / SIP INFO

Network

  • Physical: 10/100/1000 Mbps Ethernet, dual bridged port for PC bypass
  • IP Mode:IPv4
  • IP Configuration: Static / DHCP
  • Network Access Control: 802.1x
  • VPN: OpenVPN (Requires third-party app support)
  • VLAN
  • LLDP
  • CDP
  • QoS

Physical Features

  • LCD x1:7 inch (1024x600) color-screen LCD
  • Keypad: 26 keys, including
  • 5 Function keys (Hold, MWI,Mute,Headset, Redial)
  • 4 Navigation keys
  • 1 OK key
  • 1 Return key
  • 12 Standard Phone Digits keys
  • 2 Volume Control keys, Up/Down
  • 1 Hands-free key
  • HD Handset (RJ9) x1
  • Standard RJ9 Handset Wire x1
  • 1.5M CAT5 Ethernet Cable x1
  • Back Rack x1
  • RJ9 Port x2: Handset x1, Headset x1
  • RJ45 Port x2: Network x1, PC x1 (Bridged to Network)
  • USB2.0 Port x1: Standard A, Connect with Flash Driver
  • Safety keyhole x1
  • Power: 5V/2A or PoE
  • Power Consumption (PoE): 1.596~11.86W
  • Power Consumption (Adapter): 0.907~9.38W
  • Working Temperature: 0~45℃
  • Working Humidity: 10~95%
  • Installation: Desktop Stand
  • Color: Black
  • Device Dimensions
  • Desktop Stand (Angles 1): 268x185x189mm
  • Desktop Stand (Angles 2): 268x201x168mm

Protocols

  • SIP2.0 over
  • UDP/TCP/TLS
  • RTP/RTCP/SRTP
  • STUN
  • DHCPCDP
  • LLDP
  • PPPoE
  • 802.1x
  • OpenVPN (Requires third-party app support)
  • SNTP
  • FTP/TFTP
  • HTTP/HTTPS
  • TR-069
